Description
- 【High-Resolution Touchscreen】Features a 4.7-inch capacitive touch panel with 750x1334 resolution, supporting multi-touch for intuitive control of your connected devices
- 【Powerful Processing】Equipped with a quad-core ARM Cortex-A35 CPU and Mali G31-2EE GPU, ensuring smooth operation and responsive interface
- 【Versatile Connectivity】Supports both WiFi IEEE 802.11 b/g/n 2.4GHz and Zigbee 3.0 protocols, allowing for wide compatibility with various smart home ecosystems
- 【Enhanced Audio Features】Includes a 7Ω, 1W speaker for audio output and two channels of digital microphones for voice control capabilities
- 【Adaptive Brightness】Equipped with an ICC light sensor to automatically adjust screen brightness based on ambient light conditions
Specifications:
- CPU: Quad-core ARM Cortex-A35 CPU
- GPU: Mali G31-2EE GPU
- Rating: 100-240V~ 50/60Hz 5W MAX,150mA MAX
- Wireless connectivity: Wi-Fi IEEE 802.11 b/g/n 2.4GHz, Zigbee 3.0
- Screen size: 4.7" (Capacitive touch panel)
- Screen resolution: 750x1334
- Touch control: support multi-touch
- Audio output: 7Ω, 1W speaker
- Microphone: Two channels digital microphones
- Light sensor: Adjust brightness according to ambient light automatically (ICC light sensor)
- Net weight: 221g
- Applicable place: Indoor
- Working temperature: 0℃-40℃
- Working humidity: 5%~90% RH, non-condensing
- Working height: Less than 2000m
- Product dimension: 122.5x74.5x39.5mm
- Casing material: PC+CRS
- Certification: CE/FCC/ISED/RoHS
- Executive standard: EN 62368-1
Note: This product is only suitable for safe use at altitudes below 2000m.
In the box
- 1 x WiFi Smart Panel
- 1 x English User Manual
