Description
- Mini PCIE Gigabit fiber server network card is a self-developed one based on the Intel I210AT chipset network solution
- Mini PCIE single copper port RJ45 Ethernet network adapter. Support 1000M link rate automatically adapt to the existing Ethernet network
- SM-LGI210A-BT adopts miniPCIE slot design, which is widely used in industrial computer, embedded computer, single board computer, digital multimedia, etc.
- Network equipment, to solve the problem of compact equipment space. The adapter card has high performance, high stability, and very good compatibility
- Mini PCIE I210 Gigabit Ethernet adapter can be widely used in: industrial computer, embedded computer, single board computer, digital multimedia and other network equipment
- RJ45 socket, supports the following transceivers: Mini GBiC
- Chipset: Intel I210AT
- Layer 2 functions: IEEE 802.3x flow control - IEEE 802.1q VLAN
- Support Receive Side Scaling (RSS)
- Support IPv4, IPv6 protocols
- Supports 9K jumbo frames
- Support checksum offload
Specification:
- Network Type: Gigabit Ethernet
- Main Controller: Intel I210AT
- Bus card slot: mini PCIe
- Transmission medium: 1 x RJ45 interface
- Transmission rate: 1000/100/10Mbps
- Network topology:
- IEEE802.3z 1000BASE-X Gigabit Ethernet
- IEEE 802.3x Full Duplex and flow control
- IEEE 802.3ad Link aggregation for parallel links
- IEEE 802.1Q VLAN, IEEE 1588
- IEEE 802.3az - Energy Efficient Ethernet (EEE)
- Features: Support PXE, DPDK, WOL, iSCSI, FCoE, Jumbo Frame, etc
- Working temperature: 0~55℃
- Storage temperature: -40~70℃
- System Requirements: Win 7/ Server 2012/ Server2008/ Win 8/ Win 8.1/ Server2016/ Win 10, FreeBSD, for Linux, VMWare ESXi
- Cable length: 31.5cm
- MiniPCI-E main card size: 30*51mm
In the box
- 1 x Network Card
- 1 x Gigabit RJ45 Port Adapter
- 1 x Driver CD
- 1 x Cable
- 1 x Bezel
- 1 x English User Manual
