Description
-
【Professional 2-in-1 Diagnostic Tool】Combines OBDII scanner and battery tester in one device for comprehensive vehicle maintenance and troubleshooting.
-
【40,000+ Fault Code Database】Extensive fault code library with instant lookup and one-click clearing capability using F2 key for quick engine light resolution.
-
【Real-Time Vehicle Data Monitoring】Displays live data stream including speedometer, tachometer, coolant temperature, turbo pressure, voltage, and intake air temperature on HD LCD screen.
-
【Advanced Performance Testing】Conducts 0-100 km/h acceleration tests and 100 km/h braking distance measurements with real-time curve plotting and record keeping.
-
【Comprehensive Battery Analysis】Tests battery voltage, internal resistance, cold cranking amps, state of charge, and state of health with detailed diagnostic reports.
Specifications:
- Model: K2 Pro
- Product Dimensions: 171 × 87.6 × 22.8 mm (6.72 in × 3.45 in × 0.99 in)
- Operating Voltage: 5 ~ 30 V
- Working Temperature: -20 ~ 60℃
- Storage Temperature: -20 ~ 60℃
- Cable Length: 110 cm
- Battery Test Voltage Range: 6V–12V–24V Lead Acid Batteries
- Fault Code Database: 40,000+ Entries
- Display: HD LCD Screen
- Interface: 16-pin Universal OBDII, Type-C
- Status Indicators: Red (Warning), Yellow (Running), Green (Codes Cleared), Blue (Vehicle Connected)
- Supported Protocols: ISO14230-KWP, ISO15765-CAN, SAE J1850 VPW/PWM, ISO9141-2
- Languages: 15 Built-in Languages
In the box
- 1 x OBD2 Scanner
- 1 x English User Manual
