Description
- H.265 3MP camera, resolution 2304*1296
- Support 2.4ghz WiFi connection
- Support humanoid detection and motion tracking, support APP push alarm and sound alarm
- Can be controlled by PTZ, the body can be rotated 355°/90°
- Support infrared night vision, 10 infrared lights, 20m detection distance
- Support cloud storage, up to 128G memory card, support audio recording and alarm recording
- Support two-way voice
- Support multi-screen viewing at the same time
Specification:
| Model: ESCAM QF005 | ||
| app | iCSee | |
| System | OS | Embedded for Linux OS |
| System security | Account, password authority management | |
| Len | CMOS | 1/4" CMOS, support AWB, AGC, BLC |
| Lens/viewing angle | 3.6mm, angle: 72.5 degree | |
| Minimum illumination | Color: 0.1Lux, B/W: 0.01Lux | |
| IR | IR distance | 10pcs IR Led, IR distance 20m |
| IR Control | Auto | |
| Video | Video Compression | H.265/H.264+ AVI format JPEG capture |
| Resolution | Mainstream: 3MP 2304*1296 | |
| Frame rate | NTSC: 30fps/PAL: 25fps | |
| Audio | Compression | G.711A |
| Input | Built-in microphone | |
| Output | Built-in speaker(8Ω 1W) | |
| P/T | P/T function | Pan: 355°, Tilt: 90° |
| WIFI | WIFI 802.11 b/g/n(2.4G WIFI) | |
| Network interface | no RJ45 port | |
| IP address | Dynamic IP | |
| Mobile View | software for iPhone, Android(IOS4.3, Android OS 2.3 above) | |
| Alarm | Alarm detection | Support motion detection |
| Alarm action | APP push | |
| Storage | Local Storage | Support up to 128GB TF card/cloud storage |
| Other | Rated Voltage | DC5±0.3V |
| Consumption | Rated power: 3.5(IR opening )/maximum power: 7W(P/T working ) | |
| Work environment | -10~50℃ | |
| Product Weight | 180g | |
| Product size | 85*85*114mm | |
In the box
- 1 x IP Camera
- 1 x Power Adapter
- 1 x USB Cable
- 1 x Mounting Bracket
- 1 x Screw Pack
- 1 x English and Chinese User Manual
