Description
- 【Smart WiFi Circuit Breaker】Tuya smart switch integrates with WiFi for remote control and IoT functionality, perfect for smart home applications
- 【Wide Current Range】Available in multiple current ratings from 10A to 80A, catering to diverse household and commercial needs
- 【Enhanced Safety Features】Equipped with 6kA short-circuit breaking capacity and 6kV rated impulse withstand voltage for superior protection
- 【Durable Performance】Boasts a mechanical life of over 10,000 operations and an electrical life exceeding 6,000 operations, ensuring long-term reliability
- 【Environmental Resilience】Complies with stringent standards for EMC performance, surge withstand, salt spray resistance, and dust resistance, suitable for various environments
Specifications:
- Comply with standards: GB/T10963.1 IEC60898-1
- Rated voltage: AC220V
- Rated frequency: 50Hz
- Number of poles: 1P
- Pollution level: Level 2
- Protection level: IP20
- Installation category: II, III
- Specified operating temperature: -25℃~+65℃
- Frame grade rated current: 80A, 125A
- Rated current: 10A, 16A, 20A, 25A, 32A, 40A, 50A, 63A, 80A (optional)
- Instantaneous tripping form: C
- Rated short-circuit breaking capacity: 6kA
- Rated impulse withstand voltage: 6kV
- Mechanical life: more than 10,000 times
- Electrical life: more than 6,000 times
- EMC performance: in accordance with GB/T 18449
- Surge withstand: in accordance with GB/T 17626.5 Voltage 4.0KV
- Salt spray withstand: in accordance with GB/T2423.17 48h
- Dust tolerance: in accordance with GB 4208 8h
- Maximum wiring capacity: 50mm2
- Tightening torque: 4-5Nm
In the box
- 1 x Circuit Breaker
- 1 x English and Chinese User Manual
- Other items not include
